15 Shell Size available with Gold Contact Finish for MIL-DTL-38999 Series .MicroD Connector Cable,J18E2Z2H2P
Part Number:J18E2Z2H2P
Product Description:
MIL-DTL-83513 Micro-D Connector is a type of rectangular connector designed for cable-to-cable and cable-to-panel applications. It is a high-performance interconnect solution and is constructed with a durable metal shell to ensure it can withstand 500 mating cycles. The Micro-D Connector is available in shell sizes 9, 15, 25, and 37 and in male/female genders. It features copper alloy contacts and is rated for operating temperatures between -55 and +125°C. This makes it a perfect choice for various cable and cable assembly applications, such as for automotive, medical, and industrial electronics. With its high-quality and reliable performance, MIL-DTL-83513 Micro-D Connector is your go-to choice for all your interconnect needs.
Features:
- Product Name: MIL-DTL-83513 Mirco-D Connector
- Voltage Rating: 500V
- Operating Temperature: -55 To +125°C
- Contact Plating: Gold Over Nickel
- Contact Material: Copper Alloy
- Shell Material: Aluminum Alloy
- Model: J18E2Z2H2P
Technical Parameters:
| Attribute | Value |
| Cable | J18E2Z2H2P |
| Connector Type | Micro-D |
| Rectangular Connectors | Yes |
| Coupling Nut Plating | Cadmium |
| Current Rating | 5A |
| MIL Spec | MIL-DTL-83513 |
| Voltage Rating | 500V |
| Mating Cycles | 500 |
| Operating Temperature | -55 To +125°C |
| Shell Material | Aluminum Alloy |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Over Nickel |
Applications:
KAIDA's MIL-DTL-83513 Micro-D Connector is a rectangular connector with 9-50 contacts, male/female gender, and 500 mating cycles. The coupling nut is made of brass, while the insulator material is PPS. This connector is ideal for cable applications, providing a reliable connection in a compact design. Its small size and light weight make it ideal for space-restricted applications. It is also resistant to vibration, shock, and corrosion, making it suitable for harsh environments. The connector is designed to meet MIL-DTL-83513 standards, providing superior electrical and mechanical performance.
Customization:
KAIDA Micro-D Connector type J18E2Z2H2P is a high-quality product with excellent performance. It is made of aluminum alloy shell and brass coupling nut, and its operating temperature range is -55 To +125°C. Its current rating is 5A.
Support and Services:
MIL-DTL-83513 Micro-D Connector Technical Support and Service
The MIL-DTL-83513 Micro-D Connector is designed to provide reliable and secure connections in a variety of harsh environments. It is designed to meet military and aerospace requirements and is available in multiple configurations to meet a variety of application needs.
AMP offers comprehensive technical support and service for the MIL-DTL-83513 connector. Our technical team is available to answer any questions you have about the connector, from design considerations to installation and maintenance. Our team can also provide custom designs and configurations to meet your exact requirements.
Our technical support team is available Monday through Friday from 8:00am to 5:00pm EST. To contact us, please call 1-800-222-2321 or email us at techsupport@amp.com.
Packing and Shipping:
Packaging and Shipping for MIL-DTL-83513 Mirco-D Connector:
The MIL-DTL-83513 Mirco-D Connector is packaged in ESD (electrostatic discharge) bags and boxes for protection, and then placed in a cardboard box before shipping.
The packaging process is inspected and certified according to MIL-STD-2073-1E standards.
The package is then transported in accordance with the IATA/ICAO regulations for air transportation.
FAQ:
Q1: What is MIL-DTL-83513 Micro-D Connector?
A1: MIL-DTL-83513 Micro-D Connector is a reliable, high-performance, miniature connector produced by KAIDA with model number J18E2Z2H2P, which is designed for military applications and manufactured in China.
Q2: What are the main features of MIL-DTL-83513 Micro-D Connector?
A2: MIL-DTL-83513 Micro-D Connector features high performance, superior reliability, and miniature design. It is designed to meet the requirements of military applications.
Q3: What is the model number of MIL-DTL-83513 Micro-D Connector?
A3: The model number of MIL-DTL-83513 Micro-D Connector is J18E2Z2H2P.
Q4: Where is MIL-DTL-83513 Micro-D Connector manufactured?
A4: MIL-DTL-83513 Micro-D Connector is manufactured in China by KAIDA.
Q5: What are the applications of MIL-DTL-83513 Micro-D Connector?
A5: MIL-DTL-83513 Micro-D Connector is designed for military applications.
